A Large Range Flexure-Based Servo System Supporting Precision Additive Manufacturing by Mind Map: A Large Range Flexure-Based Servo System Supporting Precision Additive Manufacturing

1. Material de aluminio

2. DESING AND CONTROL

2.1. Diseño

2.1.1. It is Based on Beam Flexing

2.1.2. works with a light source and an optical system

2.1.3. It consists mainly of two stages of positioning

2.1.3.1. XY nanopositioning stage

2.1.3.2. Positioning stage is a Z-axis translator

2.1.4. Mirror symmetric arrangement

2.2. Development

2.2.1. characteristics

2.2.1.1. symmetrical mirrors that reduce parasitic movement

2.2.1.2. transverse rigidity of the beam in the form of Z

2.2.1.3. redundant flat constraints

2.2.2. NONO-POSITIONING

2.2.3. .

2.2.4. .

3. MODEL

3.1. Dynamic

3.2. Static

3.3. .

4. CONTROL

4.1. SAMPLE PROTOTYPE

4.2. Real-time control system

4.3. .

4.3.1. Prototype of the large range XY beam flexure-based nanopositioner.
