Shut down plan by Mind Map: Shut down plan

1. 1.Combustion system (Anwar)

1.1. Fuel dosing

1.2. Cylinder

1.3. Pusher

1.4. modify ผนังเตา

1.5. งาน Support เตรียมซ่อมเเซม

2. 2.Fuel handing (๋Jatuporn)

2.1. Roller

2.2. Bering

2.3. Double screw conveyor

2.3.1. Motor

2.3.2. Gear motor

2.4. Belt conveyor

3. 3.Boiler /Soot blower/Dearator (Pongpol)

3.1. Smoke test

3.2. Hydro test

3.3. Wet Pac

3.4. Fire side cleaning

3.5. FWP,Hamering Pump

3.6. Insalator testing

3.7. TN

4. 4.ESP (Pongpol)

4.1. Cleaning

4.2. Check

5. 5.Ash handing (Jatuporn)

5.1. Bering

5.2. Sprocket

5.3. chain

5.4. Scraper

5.4.1. Chain fly ash

5.4.2. Submerged chain

6. 6.Turbine/Generator (Anuwad)

6.1. Condenser

6.2. Condensate pump

6.3. Vacuum pump

6.4. Oil cooler

6.5. Grand condenser

6.6. Turbine oil

6.7. Bering

7. 7.Cooling tower (Areesa)

7.1. Gear box

7.2. Cooling air fan

7.3. Coating

7.4. Handrail

7.5. ทำความสะอาดเบซิ่น

8. 8.Disel generator/Air compresser (P'berm)

8.1. Engine

8.2. Alternator

8.3. Control

8.4. Generator Set

9. 9.Fire fighting (Safety)

9.1. Performence test

9.2. เปลี่ยน fire host

9.3. ติดตั้ง flow meter

9.4. Coating

9.5. Cleaning

10. 10. Trans former /MCC room/Medium&Low volt (Anwar)

11. 11. Water treatment (Areesa)

11.1. Coating

11.2. Cleaning
