Terrain Model by Mind Map: Terrain Model

1. 2. Physical connectivity

1.1. Node

1.1.1. Type

1.1.1.1. Switch

1.1.1.2. Router

1.1.1.3. Endpoint

1.1.1.4. Machine

1.1.2. Geographic Info

1.1.2.1. Latitude

1.1.2.2. Longitude

1.1.2.3. Building

1.1.2.4. Room

1.2. Edge

1.2.1. Bandwidth capacity

2. 3. Networks

2.1. Nodes

2.1.1. IP Address

2.1.2. MAC Address

2.1.3. VLAN

2.1.4. Host name

3. 4. Platform

3.1. Nodes

3.1.1. Operating System

3.1.2. Hypervisor

3.2. Edges

3.2.1. Networks: Assignment

3.2.2. Information Assets: Data Storage

4. People

4.1. Node

4.1.1. Name

4.1.2. Title

4.1.3. Office Building

4.1.4. Office Room

4.1.5. Telephone

4.1.6. 521

4.1.7. Mailbox

4.2. Edges

4.2.1. Administers

4.2.1.1. New node

4.2.2. Membership In

5. 5. Enabling Services

5.1. Node

5.1.1. Service Name

5.1.2. Node Type

5.1.2.1. Database

5.1.2.2. Storage

5.1.2.3. Access control

5.1.2.4. Network Infrastructure

5.2. Edges

5.2.1. Dependency

5.2.2. Networks: Address binding

5.2.3. Information Assets: Data Provider/Storage

6. 7. Mission Services

6.1. Node

6.1.1. Service Name

6.2. Edges

6.2.1. Dependency

6.2.2. Enabling Services: Dependency

6.2.3. Networks: Address binding

6.2.4. Information Assets: Data Provider

7. Task

8. Department

9. Information Assets

9.1. Node

9.1.1. Asset Name

10. Business Area

11. Sector

12. Group
