Folder Structure Brainstorm (Project) by Mind Map: Folder Structure Brainstorm  (Project)

1. Contracts

1.1. Contract and Scope Docs

1.2. Stakeholder Management

1.3. Variations

2. Model Reviews and Audits

2.1. Audit 01

2.1.1. Received files

2.1.2. WIP Files

2.1.3. Issued files

3. Marketing

3.1. Poject Logos

3.2. Approved Renders

3.3. Site Photos

3.4. Powerpoint Files

4. Project Management

4.1. Management Plans

4.1.1. 1110 Input

4.1.1.1. 1111 Client Documentation

4.1.1.2. 1112 Consultant Manuals

4.1.1.3. 1113 Software Documentation

4.1.1.4. 1114 Document Illustration

4.1.2. 1120 Work in Progress

4.1.2.1. 1121 Comments Received

4.1.3. 1130 Issued Documents

4.1.3.1. 190327 DE Govermant Mandates

4.1.3.2. 190401 Comments Included

4.1.4. 1140 Superseded

4.2. Finance

5. DE Implementation

5.1. Federation

5.1.1. 1210 Files for Federation

5.1.1.1. 1211 IFC

5.1.1.2. 1212 NWC

5.1.1.3. 1213 DWG

5.1.2. 1220 NWF

5.1.2.1. 1221 NWF backups

5.1.3. 1230 BIMflow

5.1.3.1. 1231 Appearance Spreadsheets

5.1.3.2. 1232 BIMflow Parts

5.1.3.3. 1233 DataLink Files

5.1.3.4. 1234 Testing and Audits

5.1.3.5. 1235 Superseded

5.1.4. 1240 iConstruct

5.1.4.1. 1241 Superseded

5.1.5. 1250 Navis Settings

5.1.5.1. 1251 Superseded

5.1.6. 1260 VR Output

5.2. Coordination

5.2.1. 1310 VCR Schedules

5.2.1.1. 1311 Superseded

5.2.2. 1320 VCR Models & Reports

5.2.2.1. 1321 BIMTrack Reports

5.2.3. 1330 Navisworks Settings

5.2.3.1. 1331 BIMFlow Clashes

5.2.4. 1340 BIM 360 Models

5.3. 4D

5.3.1. 1410 Sample Files

5.3.2. 1420 Program Files

5.3.3. 1430 Model Source Files

5.3.4. 1440 Working 4D Files

5.3.5. 1450 Exports, Simulations

5.4. 6D

5.4.1. 1610 COBie

5.4.2. 1620 Commissioning

5.5. WIP & Implementation

5.5.1. 1910 Testing and Troubleshooting

5.5.2. 1920 Revit

5.5.3. 1930 ArchiCAD

5.5.4. 1940 BIM360

5.5.5. 1950 dRofus

5.5.6. 1960 BIMtrack

5.5.7. 1970 Solibri

5.5.8. 1980 Specific Requests

5.5.9. 1990 VR

5.6. 5D

5.6.1. Business Development

5.6.2. 1510 Sample Files

5.6.3. 1520 Model Source Files

5.6.4. 1530 Working 5D files

5.7. Shared Folders

5.7.1. Model Exchange

5.7.1.1. Native Files

5.7.1.1.1. Revit

5.7.1.1.2. 12D

5.7.1.1.3. Aecosim

5.7.1.1.4. Tekla

5.7.1.1.5. ArchiCAD

5.7.1.2. Collaboration Files

5.7.1.2.1. IFC

5.7.1.2.2. NWC

5.7.1.2.3. DWG

5.7.1.2.4. Native Files for Coordination

5.7.1.3. Federated Models

5.7.1.3.1. Superseded

5.7.1.4. Change Registers

5.7.1.4.1. Superseded

5.7.1.5. Organisation Information

5.7.2. Software

5.7.2.1. Installers

5.7.2.2. Manuals

5.7.2.3. Settings and Samples

5.7.3. Project Documentation

5.7.3.1. Project Guides

5.7.3.2. Organisation Specific Coding Systems

5.7.3.3. Design Programs

5.7.3.4. Drawing and Report Templates

5.7.3.5. Survey Information

5.7.3.6. Drawings

5.7.4. Supporting BIM Documents

6. Correspondence

6.1. Emails

6.2. Recieved Files

6.2.1. Client Recieved Files
