Lecture 8 Mar 19 by Mind Map: Lecture 8 Mar 19
0.0 stars - reviews range from 0 to 5

Lecture 8 Mar 19

Important beginning discussion

Grounding of TDS1002 oscilloscope w/ full-wave bridge

Group work (10 minutes)

How to deal with the grounding problem?

We WANT to measure the voltage difference across two points, neither of which is ground

There are lots of answers, so try to come up with a few

Results, Can we use the DAQ board in differential mode? (Possibly...if in differential for real), Use a different oscilloscope, Traditional solution: Channel 2-1.

Introduction to transistor lab


Show lab page


First steps
