1. Microscopy Techniques
1.1. Optical Microscopy
1.1.1. Usefulness: Observing larger structures like cells and tissues. Simple and quick to use. Suitable for live cell imaging
1.1.2. Limitations: Limited resolutions and a limited depth of field
1.2. Electron Microscopy (SEM and TEM)
1.2.1. Scanning Electron Microscopy (SEM)
1.2.1.1. Usefulness: Detailed surface imaging. High depth of field
1.2.1.2. Limitations: Requires conductive coating on samples. Cannot image live cells
1.2.2. Transmission Electron Microscopy (TEM)
1.2.2.1. Usefulness: High-resolution imaging of internal structures. Can visualize macromolecular complexes
1.2.2.2. Limitations: Extensive sample preparation, including thin sectioning. Cannot image live cells
2. Protein Identification Techniques
2.1. Anitbody-Based Techniques
2.1.1. Immunofluorescence
2.1.1.1. Usefulness: Locating proteins within cells using florescently tagged antibodies. Allows for colocalization studies to see if proteins are in the same location
2.1.1.2. Connection: Can be combined with fluorescence microscopy to visualize protein location relative to organelles
2.1.2. Western Blotting
2.1.2.1. Usefulness: Detecting specific proteins in a sample using antibodies. Can quantify protein expression levels
2.1.2.2. Connection: Confirms the presence of proteins idnetified through microscopy. Can be used to validate results from other techniques
2.1.3. Mass Spectrometry
2.1.3.1. Usefulness: Identifying proteins based on their mass-tocharge ratio. Can provide detailed information about protein structure and modification. High sensitivity and specificity
2.1.3.2. Limitations: Requires purified protein samples. Complex data analysis. Expensive equipment
2.1.3.3. Connection: Can be used to analyze proteins identified via microscopy. Complements other techniques by providing detailed molecular information
2.2. Protein Interaction Studies
2.2.1. Co-Immunoprecipitation (Co-IP)
2.2.1.1. Usefulness: Isolating a protein along with its binding partners using specific antibodies. Helps identify protein complexes and interactions
2.2.1.2. Connection: Helps identify protein interactions within their native cellular context, which can be visualized using microscopy
2.2.2. Affinity Chromotagraphy
2.2.2.1. Usefulness: Purifying proteins based on specific interactions with a ligand attached to a chromatography matrix. High specificity and efficiency
2.2.2.2. Connection: Purified proteins can be analyzed using mass spectrometry for detailed molecular information. Can also be used in conjunction with other protein identification techniques like Western blotting
3. SEA -PHAGES Techniques
3.1. Phage Discovery
3.1.1. Isolation and Purification
3.1.1.1. Usefulness: Isolating new bacteriophages from environmental samples. Essential for studying plaque diversity and evolution
3.1.1.2. Connection: Can be visualized using electron microscopy to confirm the presence and morphology of phages
3.1.2. Amplification
3.1.2.1. Usefulness: Increasing the quantity of phages for further analysis. Important for subsequent steps like DNA isolation and sequencing
3.1.2.2. Connection: Amplified phages can be analyzed using various microscopy techniques to study their interactions with bacterial cells
3.1.3. Genome Analysis
3.1.3.1. DNA Isolation and Sequencing
3.1.3.1.1. Usefulness: Extracting and sequencing phage DNA to understand their genetic makeup. Crucial for identifying genes and regulatory elements
3.1.3.1.2. Connection: Sequencing data can be integrated with protein indentification techniques like mass spectrometry to study phage proteins
3.1.3.2. Bioinformatics
3.1.3.2.1. Usefulness: Analyzing genomic data using computational tools to identify genes and predict functions. Helps in understanding phage biology and evolution
3.1.3.2.2. Connection: Bioinformatic analysis can guide further experimental studies using microscopy and protein identification techniques
4. Organelle Isolation Techniques
4.1. Cell Fractionation
4.1.1. Usefulness: Separating cellular components based on size and density using centrifugation. Essential for studying specific organelles
4.1.2. Connection: Isolated organelles can be analyzed using microscopy and protein identification techniques
4.2. Density Gradient Centrifugation
4.2.1. Usefulness: Separating organelles based on their density. Provides high purity of isolated organelles
4.2.2. Connection: Purified organelles can be used for detailed protein analysis using mass spectrometry
4.3. Immunaffinity Isolation
4.3.1. Usefulness: Using antibodies to specifically isolate organelles or protein complexes. High specificity and purity
4.3.2. Connection: Isolated organelles or complexes can be analyzed using microscopy and mass spectrometry
