Transcranial Direct Current Stimulation (tDCS) by Mind Map: Transcranial Direct Current
Stimulation (tDCS)
0.0 stars - reviews range from 0 to 5

Transcranial Direct Current Stimulation (tDCS)

Learning resources


Courses, MIT 6.002


Lectures, Summit on Transcranial Direct Current Stimulation UC-Davis Sept. 5, 2013 Videos, Marom Bikson's lecture on tDCS and HD-tDCS at the Harvard Transcranial Direct Current Stimulation Course, Part 1, Part 2, tDCS for Cognitive Enhancement, Clinical Applications of Transcranial Direct Current Stimulation

Articles, General, NeuroConnections Spring 2013: Transcranial DC Stimulation, Wired Magazine: Inside the Strange New World of DIY Brain Stimulation, Hacking the brain with electricity, Electronic Stimulation could help control your dreams., Specific, Depression, Could Transcranial Direct Current Stimulation Have Unexpected Additional Benefits in the Treatment of Depressed Patients?

Research, Abstracts, Super List, Depression, Cognitive control therapy and transcranial direct current stimulation for depression: A randomized, double-blinded, controlled trial., Transcranial direct current stimulation for major depression: an updated systematic review and meta-analysis., Transcranial Direct Current Stimulation (tDCS) in Unipolar vs. Bipolar Depressive Disorder., Cognitive Performance, A Comparison of the Effects of Transcranial Direct Current Stimulation and Caffeine on Vigilance and Cognitive Performance During Extended Wakefulness, Gait Disorders, Transcranial direct current stimulation for treatment of freezing of gait: A cross-over study, Behavioral, Reducing Aggressive Responses to Social Exclusion Using Transcranial Direct Current Stimulation (tDCS)., Cravings, State dependent effect of transcranial direct current stimulation (tDCS) on methamphetamine craving., Pain, Migraine, Reduced threshold for inhibitory homeostatic responses in migraine motor cortex? A tDCS/TMS study., Brain stimulation in migraine., Transcranial Direct Current Stimulation (tDCS) of the visual cortex: a proof-of-concept study based on interictal electrophysiological abnormalities in migraine., REsults, Conclusion, Cathodal transcranial direct current stimulation of the visual cortex in the prophylactic treatment of migraine., Clinical effectiveness of primary and secondary headache treatment by transcranial direct current stimulation., Migraine prophylaxis by anodal transcranial direct current stimulation, a randomized, placebo-controlled trial., tDCS-induced analgesia and electrical fields in pain-related neural networks in chronic migraine., Abnormal changes of synaptic excitability in migraine with aura., Transcranial direct current stimulation reveals inhibitory deficiency in migraine., Chronic Pain


User Videos, anthonynlee youtube, transhumanist documentary

Electrode Positioning, International 10-20 System, The Beam F3 System, F3 calculator, Visual context, Top, Front, Placement Effects, See Montages


Current limits

Despite not being fully understood, TDCS is widely considered safe for short experimental use (Utz et al. (2010)). Work by Bikson et al. (2009) to establish rough bounds on the safe currents and exposure times for TDCS failed to produce damage to mouse brains with less than 142.9A, about 700,000 times the current used in most human trials. Further, the damage (brain lesions) scaled linearly with charge density, which is consistent with a simple burning e ect (i.e. an e ect unlikely to occur at lower amperage).


tDCS placements

Effects Chart

tDCS Protocol

1. Materials

Check if you have all materials needed


tDCS Materials


DIY, OpenStim, Hardware, Necessary, Arduino Uno - 16.99, Digital Potentiometer - 6.94, 17 Ohm resistor, Optional, OpenStim Shield from UPVERTER with compenents, Can take up to 2 month to get, OpenStim Shield from Oshpark, Printed Circuit board, Case - Plano Liqua Bait tackle box $7.50, Grommets 5/8" OD, Wiring Schematic, Single channel, Multiple Channel, Tips, Don't use breadboard with cheap flexible jumper wires, Anode Cathode configuration, Solder Connections, Windows had a conflict with OpenStim One software and bluetooth on at same time. Turning off BT fixed..not sure if same for other pc's, The dot on the digital potentiometer goes up in the diagram, Software, Java, OpenStim Zip Pkg, Upload sketch to arduino, Pros / Cons, Pros, Can do tRNS, Can do multiple electrodes, Ramping current, Digital interface, Cons, More difficult to setup, Have to troubleshoot software issues, Will only deliver 1 mA @ 5k Ohms, Developers, ohsnapitsnathan, Nicholishen2 build, pics, setup video

Off-the-shelf (Commercial), TCT ( (~$379), TDCS-Kit ($40), The Brain Stimulator ($90), Gamer ($250)

Research Models, StarStim, TCT (


About, About Electrodes and Wires

Amrex, Needs Banana Plug connectors, Available in multiple sizes, Seems to be the favorite, 3x3 most popular - sponge contact area = ~2x2

HD tDCS electrodes

DIY, Video
