C Prog Language by Mind Map: C Prog Language

1. Few Other Links

1.1. Companies using C Programming Language

1.1.1. https://docs.google.com/spreadsheet/ccc?key=0AvPic5Th8MOmdFdHc05mRHQwQmFNazk0T0N1RDRmcUE&usp=sharing#gid=0

1.2. NPTEL Videos

1.2.1. http://nptel.ac.in/courses/106104074/

1.2.2. http://ekalavya.it.iitb.ac.in/eVideos/CS101/content/preview.html

1.3. NPTEL Slides

1.4. Virtal Lab

1.5. Spoken Tutorials

2. History of C

2.1. ALGOL

2.2. BCPL

2.3. B

2.4. Traditional C

2.5. ANSI C

2.6. ANSI/ ISO C

2.7. Dennis Retchie

3. mode

3.1. r - read only

3.2. w - write only

3.3. a - appending data

4. Files

4.1. Open

4.1.1. FILE *fp; fp=fopen("filename","mode");

4.2. Close

4.2.1. fclose(file_pointer);

4.3. Input

4.3.1. putc(c, fp1);

4.3.2. c=getc(fp2);

4.4. Access

4.4.1. position

4.4.1.1. n=ftell(fp);

4.4.2. reset position

4.4.2.1. rewind(fp);

4.4.3. moving

4.4.3.1. fseek(fp,offset,position)

4.5. Output

4.5.1. fprintf(fp,"control string",list);

4.5.2. fscanf(fp,"control string",list);

5. Structures / Unions

5.1. define a structure

5.1.1. struct name; { data type member1; datatype member2;..........};

5.2. initialization members

5.2.1. main(){ struct name{ datatype mem1; datatype mem2;.....}; struct name mem1={constant.....}; struct name mem2={constant......}; }

5.2.2. struct name{ datatype mem1; datatype mem2;.....};mem1={constants.......}; main(){ struct name mem2={constants.....};...............}

6. Pointers

6.1. declaring

6.1.1. datatype *pt_name

6.2. initialize

6.2.1. p=&quantity

6.3. accessing

6.3.1. int quantity *p,n quantity=179; p=&quantity; n=*p

7. Functions

7.1. declaration

7.1.1. type name (type var1.......)

7.2. calling

7.2.1. main() { name(var1........); }

7.2.2. Call By Value - actual value of parameters

7.2.3. Call By Reference - pointers

7.3. types

7.3.1. with no arguments no return type

7.3.2. with no arguments one return type

7.3.3. with arguments no return type

7.3.4. with arguments multiple return type

7.4. definition

7.4.1. syntax

7.4.1.1. type name(type var1........) { local declaration; executable part; return(var); }

7.5. Recursion

8. Strings

8.1. Concatenation

8.1.1. strcat(str1,str2); output is str1str2

8.2. Comparison

8.2.1. strcmp(str,str2); ASCII str1 - ASCII str2, +ve if str1<str2, -ve if str1 > str2

8.3. Copying

8.3.1. strcpy(str1,str2); outputs str1="str2";

8.4. Length

8.4.1. n=strlen(str);

8.5. Substr and many more string functions are available...

8.6. Built in function in ctype.h

8.6.1. isalpha(x)

8.6.2. isdigit(x)

8.6.3. isalphanum(x)

8.6.4. ispunct(x)

8.6.5. islower(x)

9. Arrays

9.1. Dimensions

9.1.1. One

9.1.1.1. Declaration

9.1.1.1.1. type var_name[size];

9.1.1.2. Initialization

9.1.1.2.1. type name[size]={list of values};

9.1.2. Two

9.1.2.1. Declaration

9.1.2.1.1. type name[row_size] [col_size];

9.1.2.2. Initialization

9.1.2.2.1. type name[row_size] [col_size]={{row list},{col list}};

9.1.3. Multi

9.1.3.1. Declaration

9.1.3.1.1. type name[s1][s2][s3]....[sn];

9.1.3.2. Initialization

9.1.3.2.1. type name[s1][s2][s3]...[s3]={{list s1},{list s2}, {list s3}, {list s4}.....{list sn}};

9.2. Character Array (String)

9.2.1. Declaring / Initialising

9.2.1.1. char name[size];

9.2.2. Reading

9.2.2.1. scanf("%s",name);

9.2.3. Writing

9.2.3.1. printf("%s",name);

10. Design on Paper

10.1. Ms. Divya Khanure

11. Datatypes

11.1. Built-In Type

11.1.1. Integer

11.1.1.1. Signed

11.1.1.1.1. int

11.1.1.1.2. short int

11.1.1.1.3. long int

11.1.1.2. Unsigned

11.1.1.2.1. long int

11.1.1.2.2. short int

11.1.1.2.3. int

11.1.2. Float

11.1.2.1. long double

11.1.2.1.1. 80bits

11.1.2.2. float

11.1.2.2.1. 32 bits

11.1.3. Character

11.1.3.1. Signed char

11.1.3.1.1. 8bits

11.1.3.2. Unsigned char

11.1.3.2.1. 8bits

11.1.3.3. Char

11.1.4. Double

11.1.4.1. double

11.1.4.1.1. 64bits

11.2. Derived Type

11.2.1. Array

11.2.2. Funtions

11.2.3. Pointer

11.2.4. Reference

11.3. User Defined Types

11.3.1. Structure

11.3.2. Union

11.3.3. Enumeration

12. C- Tokens

12.1. Special Symbols (Delimeters)

12.1.1. ;,!?#$

12.2. Constants & Variables

12.2.1. Numeric Constants

12.2.1.1. int

12.2.1.1.1. %d

12.2.1.2. real

12.2.1.2.1. float

12.2.1.2.2. exponential

12.2.2. Character Constants

12.2.2.1. Single

12.2.2.1.1. %c

12.2.2.2. String

12.2.2.2.1. %s

12.2.2.2.2. Backslash

12.3. Keywords

12.3.1. Basic Building Blocks

12.3.1.1. int

12.3.1.2. if

12.3.1.3. case

12.3.1.4. while

12.3.1.5. struct

12.3.1.6. auto

12.3.1.7. break

12.3.1.8. case

12.3.1.9. do

12.3.1.10. for

12.3.1.11. else

12.3.1.12. continue

12.3.1.13. goto

12.3.1.14. return

12.3.1.15. switch

12.3.1.16. union

12.3.1.17. void

12.3.1.18. float

12.3.1.19. char

12.3.1.20. long

12.3.1.21. int

12.3.1.22. short

12.3.1.23. double

12.3.1.24. sizeof

12.3.1.25. typedef

12.3.1.26. register

12.3.1.27. static

12.3.1.28. const

12.3.1.29. extern

12.3.1.30. define

12.4. Identifiers

12.4.1. Ex: amount, sum etc

12.5. Strings

12.5.1. Ex" :SDMCET", "123"

12.6. Operators

12.6.1. Arithmetic

12.6.1.1. +

12.6.1.2. -

12.6.1.3. /

12.6.1.4. %

12.6.1.5. *

12.6.2. Logical

12.6.2.1. ||

12.6.2.2. &&

12.6.2.3. !

12.6.3. Assignment

12.6.3.1. +=

12.6.3.2. -=

12.6.3.3. *=

12.6.3.4. /=

12.6.3.5. %=

12.6.4. Conditional

12.6.4.1. exp1 ? exp2 : exp3;

12.6.5. Special

12.6.5.1. sizeof

12.6.5.2. , [comma]

12.6.6. Increment / Decrement

12.6.6.1. post

12.6.6.1.1. ++

12.6.6.2. pre

12.6.6.2.1. --

12.6.7. Bitwise

12.6.7.1. &

12.6.7.2. /

12.6.7.3. <<

12.6.7.4. >>

12.6.7.5. ~

12.6.8. Relational

12.6.8.1. <

12.6.8.2. <=

12.6.8.3. >

12.6.8.4. >=

12.6.8.5. ==

12.6.8.6. !=

13. Expressions

13.1. Arithmetic

13.1.1. precedence

13.1.1.1. high

13.1.1.1.1. *

13.1.1.1.2. /

13.1.1.1.3. %

13.1.1.2. low

13.1.1.2.1. +

13.1.1.2.2. -

13.1.2. example

13.1.2.1. a*b-c ->a*b-c

13.1.2.2. 3*x*x-x ->3x^2-x

13.2. Conversions

13.2.1. automatic type

13.2.1.1. follows the hierarchy of size of the operands

13.2.2. casting a value

13.2.2.1. (type name)exp;

13.3. Mathematical Functions

13.3.1. #include<math.h> cc filename -lm

13.3.1.1. example

13.3.1.1.1. exp(x)

13.3.1.1.2. fabs(x)

13.3.1.1.3. sqrt(x)

14. Input/Output

14.1. Formatted

14.1.1. Input

14.1.1.1. scanf("control string", &arg1,&arg2..);

14.1.2. Output

14.1.2.1. printf("control string", arg1,arg2..);

14.2. Unformatted

14.2.1. putchar

14.2.1.1. putchar(variable_name);

14.2.2. getchar

15. Control Statements

15.1. if

15.1.1. simple if

15.1.1.1. if(test exp){ body;} statement -x;

15.1.2. if else

15.1.2.1. if(test exp){ true-block}; else {false-block}; statement-x

15.1.3. nested if else

15.1.3.1. if(test exp1) { if(test exp2){ statement1} else {statement2;} else {statement 3}; statement-x;

15.1.4. else if ladder

15.1.4.1. if(condition1) statement1; else if(condition2) statement2; else if.........else if(condition n) statement n; else default statement

15.2. swicth

15.2.1. switch(exp){ case value1:block1; break; case value2:block2; break; ..........default:block; break; } statement-x;

15.3. conditional

15.3.1. conditional exp? exp1:true exp2:false

15.4. goto

16. Loops

16.1. continue (skip)

16.2. for

16.2.1. for(initialize ; test exp ; increment) { body; }

16.3. while

16.3.1. while(test exp) { body; }

16.4. do.. while

16.4.1. do { body ; } while(test exp);

16.5. break (jump)
