Chapter 9 Communications and Networks by Mind Map: Chapter 9   Communications and Networks

1. 6.Network Communications

1.1. Token Ring

1.2. TCP/IP

1.3. Wi-Fi 802.11

1.4. Bluetooth

1.5. IrDA

1.6. RFID (Radio Signal)

1.7. WiMAX

1.8. Wireless Application Protocal (WAP)

2. 1.Computer Communication

2.1. Sending Device

2.2. Receiving Device

3. 2.Communication Used ?

3.1. Text Messaging

3.2. Picture Messaging

3.3. Video Messaging

4. 3.Network Device Connect

4.1. Local Area Network (LAN)

4.2. Metropolitain Area Network (MAN)

4.3. Wide Area Network (WAN)

5. 4.Computer On Network

5.1. Client

5.2. Server

5.3. Peer-to-Peer

6. 5.Network Topology

6.1. Star Network

6.2. Bus Network

6.3. Ring Network

7. 7.Communication Software

7.1. Manage The Tranmission

7.1.1. Data

7.1.2. Instruction

7.1.3. Information

7.1.4. Provide an interface

8. 8.Communication Telephone Network

8.1. Dial-Up Line

8.2. Dedicated Line

8.3. ISDN

8.4. DSL

8.5. Fiber To The Premises (FTTP)

8.5.1. Fiber To The Home (FTTH)

8.5.2. Fiber To The Building (FTTB)

8.6. T-Carrier Line

8.7. ATM

9. 9.Communication Device

9.1. Dial-Up Modem

9.2. ISDN Modem

9.3. DSL Modem

9.4. Cable Modem

9.5. Wireless Modem

9.6. Network Card

10. 10.Home Network

10.1. Phoneline Network

10.2. Wi-Fi Network

11. 11.Transmission Media

11.1. Twised-Pair Cable

11.2. Coaxial Cable

11.3. Fiber-Optic Cable

11.4. Infared

11.5. Broadcast Radio

11.6. Cellular Radio

11.7. Microwave

11.8. Communication Satelline
