Shore Storage by Mind Map: Shore Storage

1. Onboard Recording of Data

1.1. ECDIS

1.1.1. GPS

1.1.1.1. Position

1.1.1.2. Speed over Ground

1.1.2. Rudder angle

1.1.3. Wind

1.1.3.1. Speed

1.1.3.2. Direction

1.1.4. Gyrocompass

1.1.5. Echosounder

1.1.6. Speedlog

1.2. Propeller Shaft Torque Meter

1.2.1. RPM

1.2.2. Torque

1.2.3. Power

1.3. ME Flowmeter

1.4. Aux Engines Flowmeter

1.5. Aux Boiler No1 Flowmeter

1.6. Aux Boiler No2 Flowmeter

1.7. Composite Boiler Flowmeter

2. Office processing

2.1. Merge Data from DANAOS

2.1.1. Summarizing Data 24Hrs Since last Departure - E Noon

2.1.1.1. Ballast

2.1.1.1.1. Distance in Miles_GPS

2.1.1.1.2. ME Revolutions

2.1.1.1.3. 24hrs Average Consuption

2.1.1.1.4. ME Consumption

2.1.1.1.5. Aux Engine Consumption

2.1.1.1.6. Aux Boiler Consumption

2.1.1.1.7. Time since last report

2.1.1.1.8. Drafts

2.1.1.1.9. Average ME Power

2.1.1.2. Ladden

2.1.1.2.1. Items 1 to 13 as ballast section

2.1.2. Sum Data Voyage Leg (Departure & Arrival) while Sailing!

2.1.2.1. Ballast Leg

2.1.2.1.1. Items 1 to 13 calculated for the period of the voyage leg

2.1.2.2. Ladden Leg

2.1.2.2.1. Items 1 to 13 calculated for the period of the voyage leg

2.1.3. Sum Data Idle or Port (Arrival & Departure) while located at same port/anchorage

2.1.3.1. Discharging at Port

2.1.3.1.1. Items 1 to 13 calculated for the period

2.1.3.2. Idle at anchorage

2.1.3.2.1. Items 1 to 13 calculated for the period

2.1.3.3. Loading at Port

2.1.3.3.1. Items 1 to 13 calculated for the period

2.2. Visual Position MAP

2.2.1. Vessel

2.2.1.1. Past 15 days

2.2.1.2. Current Voyage

2.2.1.3. Last Voyage

2.2.1.4. Historical (User time interval)

3. Danaos Vessel Reporting System
