Internet of Things (IOT) by Mind Map: Internet of Things (IOT)

1. Industrial IoT

1.1. Technologis

1.1.1. Internet

1.1.1.1. NetWork

1.1.2. Sensor nodes

1.1.2.1. Temperature Measurement

1.1.2.2. Find directions

1.1.2.3. Collect Information

1.1.3. IoT Device

1.1.3.1. Smart Device

1.1.3.1.1. Sleep Number Smart Bed

1.1.3.1.2. Roost Smart Battery

1.1.3.2. Smart Home

1.1.3.2.1. WallyHome Water Leak Detection

1.1.3.2.2. Stack’s Alba Smart LED

1.1.3.3. Smart Network

1.1.3.3.1. Network

2. Commercial IoT

2.1. Technologis

2.1.1. Micro Electro Mechanical Systems

2.1.1.1. Electrostatic Actuator

2.1.1.2. Accelerometer Sensor

2.1.2. Microservices

2.1.2.1. Application

2.1.2.1.1. Service

2.1.3. Wireless Technologis

2.1.3.1. Performance

2.1.3.1.1. Low

2.1.3.1.2. High Error Rate

2.1.3.2. Security

2.1.3.2.1. Broadcast Signals

2.1.3.2.2. Easy to be interface by then Soures

3. Flow

3.1. Step1

3.1.1. Senser/Actuator

3.1.1.1. Wied

3.1.1.2. Wireless

3.2. Step2

3.2.1. Internet Getway

3.2.1.1. Data Aggregation

3.3. Step3

3.3.1. IT

3.3.1.1. Anlysis

3.4. Step4

3.4.1. Data Center/Cloud

3.4.1.1. Data
