Core Switches Project by Mind Map: Core Switches Project

1. Scope

1.1. SHIRE HALL

1.1.1. Install 3810M Sw`s

1.1.1.1. Install physically in the RAck

1.1.1.2. Set up to handle ISCSI traffic

1.1.2. Replace 5412 from Shire Hall (SR) site to an exiting 5406 SW ( already in use for ISCSI traffic )

1.1.2.1. Remove 5412 equipment from Rack

1.1.2.2. Set up routes and rules under 5406 SW in SH site to handle with data traffic (transfer settings from 5412 equipment???)

1.1.2.3. Create Subnets (??) Question to the Datacom

1.1.3. Create redundant links

1.1.3.1. 2 additional transceivers for each site

1.1.3.2. Activate 2 additional 10 gbs fiber

1.1.4. Cables in SH

1.1.4.1. Order cables

1.1.4.2. Cable management

1.1.4.2.1. labelling

1.1.5. Install 2930 M Sw`s in SH

1.1.5.1. Install physically

1.1.5.2. Set up configurations

1.2. Depot

1.2.1. Create redundant links

1.2.1.1. 2 additional transceivers for each site

1.2.1.2. Activate 2 additional 10 gbs fiber

1.2.2. Cables in SH

1.2.2.1. Order cables

1.2.2.2. Cable management

1.2.2.2.1. labelling

2. Deliverables

3. Assumptions

4. Restrictions

4.1. Kick off Implementation - Second week of June ( 22/06 )

5. Objectives

5.1. Update part of our current environment

5.2. Provide Core/Edge separation

5.3. Improve redundancy between Primary/Secondary sites

5.4. Structure Cabling Standards

5.5. Subnet Separation

6. Risks

7. Roles/ Responsibility

7.1. Datacom

7.2. CCRC
