1. Stacks
1.1. With const time for push, pop, min
1.1.1. O(n) additional memory for havingg min(Stepi)
1.1.2. Link
1.2. Usage
1.2.1. Stacks in memory
1.2.2. In DFS
1.2.3. For saving contexts in processors
1.3. Features
1.3.1. Unknown length
1.3.2. No need to sort
1.3.3. O(1) of getting the head
2. Heap
2.1. Tree
2.2. if B is a child node of A, then key(A) ≥ key(B)
2.3. Translation to array
2.3.1. Very simple. Rows, from left to right
2.4. Algorithms
2.4.1. Heapsort
2.5. Usage
2.5.1. For top k elements
2.5.1.1. O(nlogk)
2.5.2. Heapsort (in-memory O(nlog(n))
3. Space structures
3.1. K-D tree
3.1.1. Hyperplanes
3.1.2. To the left of hyperplane - one part, to the right - second. (as a hyperplace an X axis can be used)
4. Priority Queue
4.1. Pop high-priority element: O(1)
4.2. Implementing using heap
5. In programming
5.1. Element cost in data structures
6. Trees
6.1. Trie tree
6.1.1. Link
6.1.2. Used for storing info about words
6.1.3. Easy search
6.1.4. Usage
6.1.4.1. Dictionaries
6.1.4.2. In suggest snippets
6.2. Binary
6.2.1. Unordered
6.2.2. BST
6.2.2.1. Ordered
6.2.2.2. Algorithms
6.2.2.2.1. Given a pre-order and post-order traversal results, restore te BST
6.2.2.3. Article
6.2.2.4. Usage
6.2.2.4.1. Storing data, easy access
6.2.2.4.2. Better use balanced ones
6.3. In programming
6.3.1. Scaling
6.3.1.1. Trees scale not good. HashMap is better
6.4. Algorithms
6.4.1. Generate all possible trees
6.5. Self-balancing
6.5.1. RB tree
6.5.1.1. Rotation
6.5.1.1.1. quite simple
6.5.1.2. Rules
6.5.1.2.1. Root: black
6.5.1.2.2. Red can have only black childs
6.5.1.2.3. Black height of each leaf is const
6.5.2. AVL
6.5.2.1. First such structure
6.5.2.2. Balance factor (-1, 0, 1)
6.5.2.3. Flips
6.5.2.4. Wiki
6.5.3. Usage
6.5.3.1. For storing sorted data where access time equal to log(n) is needed
6.5.3.2. Representing hierarchies
6.6. B-tree
6.6.1. Complexity
6.6.1.1. O(logn)
6.6.2. Leaves and nodes contain elements
6.6.3. Links to next elements (organize single-linked list)
6.7. B+ tree
6.7.1. Nodes don't contain data, only leaves
6.7.2. Leaves organize wide list
6.7.2.1. Easy iteration, easy deletion
6.7.2.1.1. A big plus in block systems
6.7.3. Usage
6.7.3.1. Block data systems
6.7.3.1.1. File systems
6.7.3.1.2. RDBMS (storing blobs?)
6.8. 2-4 Trees
6.8.1. Like B trees with 2,3 or 4 children
6.9. Interval tree
6.9.1. Usage
6.9.1.1. Queues
6.9.1.2. Graphics (finding overlap zones)
6.10. General usage
6.10.1. Hierarchies
6.10.2. DOM, XML
6.11. Fenwick tree
6.11.1. Quick calculation sum of elements from i to j in arrays
7. Linked list
7.1. Algorithms
7.1.1. Determine whether has cycles
7.1.1.1. Article
7.1.1.2. Idea
7.1.1.2.1. 2 pointers
7.1.1.2.2. 1 pointer has speed 1 el/iteration, another - 2 el/iteration
7.1.1.2.3. If they visit before the first pointer reaches the end - has cycles
7.1.1.2.4. O(n) worst case, no additional memory
7.1.2. Reverse linked list
7.1.2.1. Article
7.1.2.2. O(n)
7.2. Usage
7.2.1. For queries
7.2.1.1. Messaging
7.2.1.2. Scheduling
7.2.1.3. In BFS, DFS algorithms
7.2.2. Where number of items is unknown
8. Probabilistic
8.1. Bloom Filter
9. Graphs
9.1. Algorithms
9.1.1. Traversal
9.1.1.1. BFS
9.1.1.1.1. Nearest elements are added to the end of query
9.1.1.2. DFS
9.1.1.2.1. Nearest els are added to the begin of the query
9.1.2. Prim apgorithm - find the minimal spanning tree
9.1.2.1. Select any vertex
9.1.2.2. Each step add to the tree the nearest edge with min weight
9.1.3. Does represent a tree?
9.1.3.1. No cycles
9.1.3.2. Linked
9.1.3.3. Article
9.1.4. Longest path in graph
9.1.4.1. Article
9.1.5. Paths rom all to all
9.1.5.1. Warshall-Floyd algorithm
9.1.5.1.1. O(n^3)
9.1.5.1.2. Link
9.1.6. Min path
9.1.6.1. Dijkstra algorithm
9.1.7. A*
9.1.7.1. Improvement of Dijkstra algorithm
9.1.7.2. Uses heuristics
9.1.7.3. Result is sum of 2 functions: minDistance + h(x). h(x) is heuristical function
9.1.7.3.1. Named 'best-first'
9.2. Directed
9.2.1. weighted
9.2.1.1. Dijkstra algorithm - find min distance from one vertex to anothers
9.2.1.1.1. Link
9.2.1.2. Impl
9.3. Acyclic
9.3.1. Path between two vertices
9.3.1.1. Article
9.4. Usage
9.4.1. Representing complex structures
9.4.2. Modelling (networks, etc)
10. HashMap
10.1. Implementation
10.1.1. non-threadsafe
10.1.1.1. Article
10.1.1.2. hash function
10.1.1.2.1. h ^= (h >>> 20) ^ (h >>> 12); return h ^ (h >>> 7) ^ (h >>> 4);
10.1.1.3. default initial capacity - MUST be a power of two.
10.1.1.4. Max capacity MUST be a power of two
10.1.1.5. load factor
10.1.1.6. Index of element
10.1.1.6.1. hash & (length - 1)
10.1.2. threadsafe
10.1.2.1. Simple
10.1.2.1.1. Lack of scalability bacause of locks
10.1.2.2. ConcurrentHashMap
10.1.2.2.1. Segments
10.1.2.2.2. Further improvement with buckets
10.1.2.2.3. coucurrencyLevel
10.1.2.3. Article
10.2. Usage
10.2.1. Caches
10.2.2. Storing data with keys
10.2.3. One of most useful data structures
11. Array/List
11.1. Algorithms
11.1.1. Sorting
11.1.1.1. Bubble sort
11.1.1.1.1. One of the slowest
11.1.1.1.2. O(n^2)
11.1.1.1.3. Complete loop from 0, 1...n-1 el
11.1.1.2. Merge sort
11.1.1.2.1. O(nlogn)
11.1.1.2.2. Article
11.1.1.2.3. Idea
11.1.1.3. Insertion ort
11.1.1.3.1. Worst case: O(n^2)
11.1.1.3.2. Best case: O(n)
11.1.1.3.3. Idea
11.1.1.4. Bucket sort
11.1.1.4.1. Article
11.1.1.5. Quicksort
11.1.1.5.1. Complexity
11.1.1.5.2. Idea
11.1.1.6. Table of complexity
11.1.1.7. Radix sort
11.1.1.7.1. O(mk)
11.1.1.7.2. Sort last set of digits, then sort previous etc
11.1.1.8. Heapsort
11.1.1.8.1. in-memory
11.1.1.8.2. Complexity
11.1.1.9. Counting sort
11.1.1.9.1. Linear time, linear space
11.1.1.9.2. Used for data in small ranges
11.1.2. Max increasing sequence in an array
11.1.2.1. Article
11.1.2.2. Complexity
11.1.2.2.1. Time: O(n^2)
11.1.2.2.2. Memory: O(n)
11.1.2.3. Idea
11.1.2.3.1. Use accumulatedLength for each element
11.1.3. Min and max elements
11.1.3.1. Recursive
11.1.3.1.1. Sort (nlogn)
11.1.3.1.2. Find (n)
11.1.3.2. Non-recursive
11.1.3.2.1. O(n)
11.1.3.3. Article
11.1.4. Find firt pair of dublicates
11.1.4.1. Additional memory
11.1.4.1.1. HashMap with occurences
11.1.4.1.2. O(n) time O(n) worst case map
11.1.4.2. Without additional memory
11.1.4.2.1. O(nlogn)
11.1.5. Find common elements in 2 arrays
11.1.5.1. Article
11.1.5.2. Idea
11.1.5.2.1. Sort both arrays: O(m) and O(n)
11.1.5.2.2. Walt through both: O(m+n)
11.1.6. Find a number in a sorted array
11.1.6.1. Idea
11.1.6.1.1. Dichotomy method
11.1.6.2. Article
11.1.7. Find a median in distributed collection on thouands of servers
11.1.7.1. Article
11.1.7.2. Idea
11.1.7.2.1. Median of medians
11.1.7.2.2. O(n)
11.1.8. Maximum contigious ubsequent sum problem
11.1.8.1. Article
11.1.8.2. Idea
11.1.8.2.1. Walk from 0 to n-1
11.1.8.2.2. If accumulated sum is negative - reset
11.2. Usage
11.2.1. For storing indexed data
11.2.2. When element size matters (approx 8 times less than other data structures)
