ZINC TEST by Mind Map: ZINC TEST
0.0 stars - 0 reviews range from 0 to 5

ZINC TEST

BENCH TEST

SELECT COM/ SELECT LTB/SSB

IDENTIFY TOOL FOR COMMUNICTION

CHECK FRIMWARE REV.

FILE UTILITIES MENU

CREATE A FILE

MONITOR CHANNELS

RECORD DATA TO THE EXCELL SHEET TO CHECK PASS OR FAIL RESULT.

MEMORY MENU

ERASE-WRITE-READ-ERASE CHECK ALL MEMORY RECORDING. TAKES 12 MINS

CALIBRATION MENU

ERASE-WRITE-READ CHECK CALIBRATION PAGE. TAKE 4 MINUTES

HEAT TEST

SET TEMPATURE 70

TEMP STABLE BEFORE TESTING

MONITOR CHANNELS

CALIBRATION MENU

READ CHECK CALIBRATION PAGE CHECK PASS/FAIL

SET TEMPATURE

100 DEGREES 120 DEGREES STEPS SAME AS ABOVE

MONITOR CHANNELS

CALIBRATION MENU

READ CHECK CALIBRATION PAGE CHECK PASS/ FAIL RESULTS EXCELL SPREADSHEET

SET TEMPATURE 155

TEMP STABLE BEFORE TESTING

MONITOR CHANNLES

MEMORY MENU

WRITE-READ-CHECK ALL RECORDING MEMORY. PASS/FAIL RESULTS

SET TEMPATURE 40

TEMP STABLE BEFORE TESTING

MONITOR CHANNELS

MEMORY MENU

1. READ CHECK ALL RECORDING MEMORY. 2.ERASE-WRITE-READ-ERASE CHECK ALL MEMORY RECORD PASS/FAIL

CALIBRATION MENU

1.READ CHECK CALIBRATION PAGE 2,ERASE-WRITE-READ CHECK PAGE RECORD PASS/FAIL

SHOCK TEST

FILE UTILITIES MENU

CREATE A FILE

BEFORE SHOCK

MONITOR CHANNELS

SHOCK TEST

The shock test consists of 250 drops on each of 4 axes. Machine is set to 250 G. During shocks

AFTER SHOCK

MONITOR CHANNELS

CALIBRATION

CALIBRATION MENU

IMPORT MANUFACTURER COEFFICIENTS

perform calibration

compute calibration coefficients

load calibration coefficient

display tool’s calibration coefficients

perform calibration check

create summary
