Immunity Response by Mind Map: Immunity Response

1. Specific

2. Non Specific

3. External Defence

3.1. Hair , Cilia, Mucus membrane, Flushing action , Cerumen, Skin, Lysozyme, Acids

4. Protective Reflex

4.1. Sneezing, Coughing, Diarrhoea,Vommiting

5. Internal Non Specific Reflex

5.1. Phagocyes

5.1.1. Macrophage and Neutrophil-engulf and digest antigen - Not discriminate

5.2. Inflammation

5.2.1. Reddish,Warm-Vasodilation of blood vessel as a result of histamine, Pain-Pain receptor stimulated, Swelling-Plasma inside the blood flow out

5.3. Fever

5.3.1. Because of lymphocyte secreting Pyrogene -Body thermostat set body temperature at higher level - not suitable for pathogen and increase rate of reaction of macrophage

6. Cell-Mediated Immunity

6.1. Role player:T lymphocyte-Produce in bone marrow mature at thymus

6.2. T lymphocyte is activated after binding to antigen on APC, sensitised , enlarge and divide

6.3. Form Clone - Helper T Cell, Suppressor T cell, Killer T cell and memory T-cell

6.4. Helper T- secrete cytokines (Interleukin 2)~Stimulate maturation of B cells, activate more lymphocyte at site of infection, attract macrophage , enhance phagocytic action

6.5. Killer T cell-secrete granzyme and perforin -causes cells undergo suicide(Apoptosis)

6.6. Suppressor T cell- inhibit B and T cells after the all the pathogen is killed or to control the activity of B and T cells

6.7. Memory T cell-Responsible for secondary response making body able to react faster if the same pathogen invade the body again

7. Antibody Mediated Immunity

7.1. Role Player-B cells~Produce and mature at bone marrow

7.2. B cells is activated after binding to antigen,sensitised , enlarge and divide

7.3. Form clone-Plasma cells and memory B cells

7.4. Plasma Cell- Secrete antibody into bloodstream

7.4.1. Antibody can:

7.4.2. Combine with foreign bacteria toxin, inactivate them by inhibiting reaction with other cell(Neutralisation )

7.4.3. Bind to surface-prevent antigen from entering the cell(Neutralisation )

7.4.4. Coat the pathogen-easier for phagocyte to engulf and digest(Opsonisation )

7.4.5. Clump antigen together (Agglutination)

7.4.6. Dissolve pathogen

7.4.7. Making soluble pathogen to insoluble ( Precipitation )

7.5. Memory B cell- Enable body to make more antibody at a faster rate if the same antigen invade body again
